Woltman Turbine R160 Cold Water Meter



Brand Name	NWM
Model	WP-SDC PLUS
Sort	Mechanical Drive
Type	Woltman
Body Material	Ductile Iron
Ratio	Class C/R160/200/250
Size	Dn40/50/65/80/100/125/150/200
Customized Support	OEM, ODM
Communication Port	Pulse / NB-IoT / LoRa / LoRaWAN / M-Bus / RS485
Installation Mode	Horizontal Installation
Temperature Class	T30 (cold water)/T50
Pressure Rating	MAP16
Certificate	CE/ MID 2014/32/EU
Place of Origin	Ningbo, China
Warranty	2 years
Waterproof Rating	IP68



NWM WP-SDC Plus is a Woltman turbine water meter with magnetic transmission, and super dry type register for Industrial and irrigation applications has sizes from Dn50 to Dn200 designed by NWM and meets the requirements of Directive 2004/22/EC on measuring instruments and of European Standard EN14154.





● The high technology of Hydraulic Dynamic Balance for the Turbine at horizontal direction for long working life;

● WP-SDC PLUS woltman water flow meter has double rectifier for stable water flow;

● All the materials in contact with water, consciously selected by the known resistance to corrosion;

● Ductile Iron body with inside and outside epoxy coating for protecting the corrosion;

● The ROTATING indicator register for the most comfortable reading position;

● The copper can super dry indicator register with IP68 protection for most reliable,The interchangeable,removable measuring mechanism can be easy removed from the body for checking, maintaining and replacing, no needs to dismantle the body form the pipe;

● Suitable for any position installation including Horizontal, Vertical and Inclined;

● Low pressure loss;

● No effected by external magnetic fields;

● NWM WP-SDC-Plus woltman water flow meter is able to compatible with HR Radio Module.

● Option to prepared with HR system for wireless transmit facilitates (walk by or fixed network)

● IP68 design with various applications service for long life (at least 12 years)

● The data collection system could compatible with water meters equipped with the non-magnetic target







The Flange Standard under ls0 7005-2:1998(E)PN16 as



*Different Flange Standard for selecting such as: ISO 7005-2: 1998(E)PN10, ASME B16.1-Class 125; working for B16.5-Class 150...









a.From Q1 inclusive up to but excluding Q2 is ±5%;
b.From Q2 inclusive up to and including Q4 is ±2% for T30 and ±3% for T50;





HR Radio Module pre-equipment with inductive plate:





● NWM WP-SDC Plus woltman turbine water meter can be installed in any position including Horizontal, Vertical and Inclined with the direction of the flow as indicated by the arrow cast in the meter body; Ø

● NWM WP-SDC Plus woltman turbine water meter needs to have 10 diameters straight pipe ahead of the meter and 5 diameters straight pipe after to insure proper flow through the meter;

● Pipeline must be flushed before installation;

● The meter should be constantly full of water during operation; Ø

● NWM suggestion to install the FILTER before the water meter.
